H2O2 Low Temperature Plasma Sterilizer AM-APS-0.4X
- Home
- H2O2 Low Temperature Plasma Sterilizer AM-APS-0.4X
Personal Protective Equipment
Laboratory Equipment
Operating Theatre Equipment
-
Hydrogen Peroxide Plasma Technology
Utilizes H2O2 plasma for effective sterilization of heat-sensitive instruments. -
Low Temperature Operation
Operates at low temperatures, ensuring the safe sterilization of delicate items without heat damage. -
Compact Design
Space-efficient design fits in tight spaces while maintaining powerful sterilization performance. -
User-Friendly Control Panel
Features an intuitive control panel for easy operation and monitoring. -
Customizable Settings
Allows for adjustable settings to meet specific sterilization needs for different types of instruments. -
Built-in Safety Features
Includes automatic shutoff in case of malfunction to ensure safety during operation. -
Monitoring System
Integrated monitoring systems provide real-time updates and consistent, reliable sterilization results. -
Eco-Friendly Sterilization
Offers an environmentally friendly solution by minimizing the use of harmful chemicals. -
Efficient Sterilization Process
Provides fast and effective sterilization, saving time while ensuring thorough cleaning. -
Ideal for Heat-Sensitive Instruments
Perfect for sterilizing medical, dental, and laboratory equipment that cannot withstand high temperatures.
| PARAMETER | SPECIFICATION | ||
| Chamber dimension/volume | APS-0.4X：650D*380W*260Hmm/64L | ||
| Chamber structure and material | Rectangular shape
Aluminum alloy material |
||
| Overall dimension | APS-0.4X: 850D×725Wx750Hmm | ||
| Door quantity and type | Single door, manual door
operation on touch screen |
||
| Loading method | Shelf loading, double layers | ||
| Installation form | Installation on the ground | ||
| Program | Standard cycle | flash cycle | Leak test |
| Sterilization cycle time | ≤35mins | ≤23mins | |
| Sterilization temperature | 50℃±5℃ | ||
| Sterilization medium | H2O2 Solutions, 60% concentration | ||
| H2O2 Solutions injection mode | Cassette type,
12 capsules on each cartridge 1.2ml H2O2 per capsule. |
||
| H2O2 Solutions consumption | APS-0.4X: 2 capsules per full cycle, 1 capsules per flash cycle | ||
| Weight | 200Kg | ||
| Power supply | Driving power: AC 380 V ± 10% 3 phases 50 Hz, 2kw | ||
| Display and operation | 5.7’’ true color Touch screen display and operation | ||
| Data printer | Built-in thermal printer | ||
| Loading method | Loading shelves | ||
| Safety system | |||
| Door safety | Adapts mandril-driving automatic door with reliable sealing function and safe lock device to guarantee the personal safety. | ||
| Alarm | The machine equips with visible alarm information when error occurs. | ||
| Environment safe | The matter after sterilization is water and oxygen molecule that have no toxic harm to staff or patient and there is no need for draining or air exhausting. | ||
| Component material | |||
| Chamber | Aluminum alloy | ||
| Chamber insulation material | High quality sponge | ||
| Outside cover | Glass fiber reinforced plastics | ||
| Door seal | Silicon rubber | ||
| Chamber support | Carbon steel welded | ||
| Pipeline system | Stainless steel and copper | ||
| Internal loading rack | Stainless steel | ||
| External transfer trolley | No. | ||
| Configuration List | |||
| Chamber body | PS40.1 | ARI | Stainless steel mirror board |
| Door | PS40.2 | ARI | Stainless steel and color glaze tempered glass |
| PLC | CUP226 | SIEMENS, Germany | Strong function，advanced performance，high reliability, Multi communication mode. |
| 5.7’’ touch screen | T6457-D-S | ARI | Colorful display, real-time parameter display, convenient |
| Printer | SPIB | ARI | Thermal printer, can print temperature, time, pressure and curve graph and sterilization result. |
| Vacuum pump | ARI | High rate of flow, low noise | |
| High precision pressure transmitter | Setra | USA | Import from America, High precision detection |
| Pressure transmitter | Wika | Germany | Import from Germany, High accuracy |
| Temperature sensor | PT-100 WIKA | Germany | |
| Plasma power | ARI | High frequency | |
| Solenoid valve | SMC, Japan | Stable with long service life | |
| Air filter | Sartorius stedim | ||
| Curve for cycle | |||
| Working process
Pre-vacuum → Pre-plasma → Ventilation 1 → Purification 1 →Diffusion1→ Ventilation2→ Vacuum2→ Plasma1 → Ventilation3 → Purification2 → Diffusion2 → Ventilation4 → Vacuum3 → Plasma2 → Ventilation5 |
|||
| Standard and certificate | |||
| ISO13485, CE. | |||
| Consumables | |||
| Name | Specification | Consumption | Photo reference |
| H2O2 cassette | 12 capsules in one piece. | APS-0.4X:
6 standard cycles for each cassette |
|
| Biological indicator | 50 pieces in one box. | 2 pieces per day | |
| Chemical indicator | 10cm x 1.8 cm
200 pieces in one bottle |
5-10 piece per cycle | |
| Indicating Label for (Red/Green) | 2.5cm×6cm
18000pieces/20Bags/Case |
Depends on sterilizer items | |
| Paper-plastic pouch | 75mm X 100m | Depends on sterilizer items | |
| 100mm X 100m | |||
| 150mm X 100m | |||
| 200mm X 100m | |||
| 250mm X100m | |||
| 300mm X100m | |||
| Non-woven fabric cloth | 300mm×300m | Depends on sterilizer items | |
| 400mm×400m | |||
| 450mm×450m | |||
| 500mm×500m | |||
| 600mm×600m | |||
| 700mm×700m | |||
| 800mm×800m | |||
| 900mm×900m | |||
| 1000mm×1000m | |||
| 1100mm×1100m | |||
| 1200mm×1200m | |||
| Sterilization Crepe Paper
(Color optional: Blue, White, Green) |
300mm×300m | Depends on sterilizer items | |
| 400mm×400m | |||
| 500mm×500m | |||
| 600mm×600m | |||
| 750mm×750m | |||
| 900mm×900m | |||
| 1000mm×1000m | |||
| 1200mm×1200 |
