H2O2 Low Temperature Plasma Sterilizer AM-APS-1X/2X
- Home
- H2O2 Low Temperature Plasma Sterilizer AM-APS-1X/2X
Personal Protective Equipment
Laboratory Equipment
Operating Theatre Equipment
-
Hydrogen Peroxide Plasma Technology
Utilizes H2O2 plasma for safe and effective sterilization of heat-sensitive instruments. -
Low Temperature Operation
Sterilizes at low temperatures to prevent damage to delicate equipment. -
Ideal for Heat-Sensitive Instruments
Perfect for medical, dental, and laboratory instruments that cannot withstand high temperatures. -
User-Friendly Interface
Features an intuitive control panel for easy operation and monitoring. -
Customizable Sterilization Settings
Offers adjustable settings to meet specific sterilization requirements for various types of instruments. -
Built-in Safety Features
Includes automatic shutoff to ensure safety in case of a malfunction. -
Compact and Space-Efficient Design
Space-saving design fits into tight spaces without sacrificing performance. -
Real-Time Monitoring System
Integrated monitoring systems provide real-time updates for consistent, reliable results. -
Eco-Friendly Sterilization
Provides an environmentally friendly solution by reducing the use of harmful chemicals. -
Fast and Efficient Process
Delivers fast sterilization without compromising effectiveness, saving both time and resources.
| PARAMETER | SPECIFICATION | ||
| Chamber dimension/volume | APS-1X/1XP：750D*450W*400Hmm/135L APS-2X/2XP：1250D*450W*400Hmm/225L | ||
| Chamber structure and material | Rectangular shape Aluminum alloy material | ||
| Overall dimension | APS-1X/1XP：990D×760Wx1600Hmm APS-2X/2XP：1460D×760Wx1600Hmm | ||
| Door quantity and type | Single door, floor standing, automatic vertical sliding, operation on touch screen | ||
| Loading method | Shelf loading, double layers | ||
| Installation form | Installation on the ground | ||
| Program | Standard cycle | flash cycle | Leak test |
| Sterilization cycle time | ≤50mins | ≤26mins | |
| Sterilization temperature | 50℃±5℃ | ||
| Sterilization medium | H2O2 Solutions, 60% concentration | ||
| H2O2 Solutions injection mode | Cassette type, 12 capsules on each cartridge 2.2ml H2O2 per capsule. | ||
| H2O2 Solutions consumption | APS-1X/1XP: 2 capsules per full cycle, 1 capsules per flash cycle APS-2X/2XP: 4 capsules per full cycle, 2 capsules per flash cycle | ||
| Weight | 135L:400kg / 225L: 500Kg | ||
| Power supply | Driving power: AC 380 V ± 10% 3 phases 50 Hz, 3.8kw（4.7kw） | ||
| Display and operation | 5.7’’ true color Touch screen display and operation | ||
| Data printer | Built-in thermal printer | ||
| Loading method | Loading shelves | ||
| Safety system | |||
| Door safety | Adapts mandril-driving automatic door with reliable sealing function and safe lock device to guarantee the personal safety. | ||
| Alarm | The machine equips with visible alarm information when error occurs. | ||
| Environment safe | The matter after sterilization is water and oxygen molecule that have no toxic harm to staff or patient and there is no need for draining or air exhausting. | ||
| Component material | |||
| Packing size/G.W | 300mm*260mm*160mm, 3.5KG | ||
| Component | Material | ||
| Chamber | Aluminum alloy | ||
| Chamber insulation material | High quality sponge | ||
| Outside cover | Glass fiber reinforced plastics | ||
| Door seal | Silicon rubber | ||
| Chamber support | Carbon steel welded | ||
| Pipeline system | Stainless steel and copper | ||
| Internal loading rack | Stainless steel | ||
| External transfer trolley | No. | ||
| Configuration List | |||
| Chamber body | PS100.1 | ARI | aluminum alloy chamber, both side welding, chamber warranty > 10 years |
| Door | PS100.2 | ARI | Stainless steel and color glaze tempered glass |
| PLC | CUP226 | SIEMENS, Germany | Strong function，advanced performance，high reliability, Multi communication mode. |
| 10’’ touch screen | T6457-D-S | ARI | Colorful display, real-time parameter display, convenient |
| Printer | SPIB | ARI | Thermal printer, can print temperature, time, pressure and curve graph and sterilization result. |
| Vacuum pump | ARI | High rate of flow, low noise | |
| High precision pressure transmitter | Setra | USA | Import from America, High precision detection |
| Pressure transmitter | Wika | Germany | Import from Germany, High accuracy |
| Temperature sensor | PT-100 WIKA | Germany | |
| Plasma power | ARI | High frequency | |
| Solenoid valve | SMC, Japan | ||
| Air filter | Sartorius stedim | ||
| Biological Incubator (APS-1XP, APS-2XP) | The incubator is integrated with the equipment, and has independent control system, which can operate independently in the state of shutdown, and can be cultivated and operated conveniently. | ||
| Curve for cycle | |||
| Working process Pre-vacuum → Pre-plasma → Ventilation 1 → Purification 1 →Diffusion1→ Ventilation2→ Vacuum2→ Plasma1 → Ventilation3 → Purification2 → Diffusion2 → Ventilation4 → Vacuum3 → Plasma2 → Ventilation5 | |||
| Standard and certificate | |||
| ISO13485, CE. | |||
| Consumables | |||
| Name | Specification | Consumption | Photo reference |
| H2O2 cassette | 12 capsules in one piece. | APS-1X/1XP: 2 standard cycles for each cassette APS-2X/2XP: 4 standard cycles for each cassette | |
| Biological indicator | 50 pieces in one box. | 2 pieces per day | |
| Chemical indicator | 10cm x 1.8 cm 200 pieces in one bottle | 5-10 piece per cycle | |
| Indicating Label for (Red/Green) | 2.5cm×6cm 18000pieces/20Bags/Case | Depends on sterilizer items | |
| Paper-plastic pouch | 75mm X 100m | Depends on sterilizer items | |
| 100mm X 100m | |||
| 150mm X 100m | |||
| 200mm X 100m | |||
| 250mm X100m | |||
| 300mm X100m | |||
| Non-woven fabric cloth | 300mm×300m | Depends on sterilizer items | |
| 400mm×400m | |||
| 450mm×450m | |||
| 500mm×500m | |||
| 600mm×600m | |||
| 700mm×700m | |||
| 800mm×800m | |||
| 900mm×900m | |||
| 1000mm×1000m | |||
| 1100mm×1100m | |||
| 1200mm×1200m | |||
| Sterilization Crepe Paper (Color optional: Blue, White, Green) | 300mm×300m | Depends on sterilizer items | |
| 400mm×400m | |||
| 500mm×500m | |||
| 600mm×600m | |||
| 750mm×750m | |||
| 900mm×900m | |||
| 1000mm×1000m | |||
| 1200mm×1200m |
